Picosecond laser is an advanced beauty technology with multiple functions such as whitening and removing spots, tattoos, improving fine lines and skin rejuvenation, providing an efficient and safe choice for those who pursue beauty. Risu Tech provides a complete product solution for peers in the industry. This product has been fully tested and verified and fully meets the standards for medical registration. Risu Tech can assist customers in registration and certification, and provide OEM services.
This product features a modular design for easy maintenance and a system with self-diagnostic capabilities. In case of a malfunction, the system provides specific error prompts to facilitate quick identification and resolution of issues. The product is equipped with a mechanical shutter, significantly enhancing its safety. The principle of the mechanical shutter is to insert an obstructive element into the optical path, which can cut off the beam even in the event of an electrical failure, thereby preventing accidental injuries. Additionally, the product is fitted with an energy feedback module that can monitor the laser pulse energy in real-time. If the actual energy deviates significantly from the set energy, the system promptly alerts the user, thereby preventing accidental injuries due to excessive energy or compromised treatment effectiveness due to insufficient energy during normal use.
| Wavelength | 1064nm, 532nm |
| Max Single Pulse Energy | 500mJ@1064nm, 250mJ@532nm |
| Output Energy Range | 100-500mJ@1064nm, 50-250mJ@532nm |
| Max Energy Density | 15.9J/cm2@1064nm, 8.0J/cm2@532nm |
| Repetition Rate | 1-10Hz |
| Pulse Width | 300-500ps |
| Beam Spot Size | 2-10mm |
| System Cooling | Water Cooling, TEC, Cooling fan |
| Dimension | 537.5mm×1032.6mm×1580mm |
The picosecond laser has an extremely narrow pulse width and ultra-high peak power. It can remove pigment targets at targeted locations through selective photothermal and photomechanical effects without harming normal tissue. It has become very popular in the medical beauty industry in recent years. As a source manufacturer of laser medical equipment accessories, Lingsu Medical Technology has launched a series of ODM kit products called PFxx “Nd:YAG/KTP Picosecond Laser System” in order to meet application needs. The laser pulse width is 350ps/500ps/2ns, and the single Pulse energy 500mJ/350mJ@1064nm is optional, and the peak power can reach up to 1.43GW. A variety of lasers, power supplies, and light guide arms are optionally available, and dye wavelength conversion and honeycomb lattice technology can be implemented. Other configurations can be customized.
